Industrial Revolution

By SkylerG
  • The Flying Shuttle

    The Flying Shuttle

    Allowed the shuttle, containing the thread, to be shot backwards and forwards across a much wider bed. The flying shuttle also allowed the thread to be woven at a faster rate,invented by John Kay.
  • Spinning Jenny

    Spinning Jenny

    Spinners produced thread faster than weavers could use, invented by James Hargreaves
  • Puddling

    Puddling

    Used to burn away impurity and crud iron, and produce a iron of high quality, invented by Henry Cort
  • Water powered loom

    Water powered loom

    It was possible for the weaving of cloth to catch up with the weaving of thread, invented by Edmund Cartwright
  • Cotton Gin

    Cotton Gin

    The process uses a small screen and pulling hooks to force the cotton through the screen, it was invented by Eli Whitney
  • INTERCHANGEABLE PARTS

    INTERCHANGEABLE PARTS

    A manufacturing method based on interchangeable parts: the idea being that if all individual pieces of a machine are produced, built by Eli Whitney.
  • Steam locomotive

    Steam locomotive

    Could pull 10 tons of ore and 70 people at 5 mph, Build by Richard Trevithick
  • Paddle Wheel steam boat

    Paddle Wheel steam boat

    Made transportation easier on the water ways, built by Robert Fulton
  • The Blucher

    The Blucher

    The first successful flange wheel locomotive, Built by George Stephenson.
  • Factory Act

    Factory Act

    Improved conditions for children working in the factories
  • Assembly Line

    Assembly Line

    An assembly line is a manufacturing process in which parts are added as the semi-finished assembly moves from workstation to workstation where the parts are added in sequence until the final assembly is produced, developed by Samuel Colt.
  • Telegraph

    Telegraph

    Transmittes electric signals over wires from location to location and then translated into a message, Invented by Samuel F. B. Morse
  • Steel Plow

    Steel Plow

    Was used for farming to break up tough soil without soil getting stuck to it, invented by John Deere
  • vulcanized rubber

    vulcanized rubber

    Made to be melt proof and reliable, developed by Charles Goodyear
  • Sewing Machine

    Sewing Machine

    The first sewing needles were made of bones or animal horns and the first thread was made of animal sinew, invented by Elias Howe
  • Steel-making

    Steel-making

    A system of air blowing the carbon out of pig iron, invented by Henry Bessemer
  • Telephone

    Telephone

    A devices that could transmit speech electrically, Invented by Alexander Graham Bell
  • Induction Electric Motor

    Induction Electric Motor

    An electric motor built off of the diesel motor, built by Nikola Tesla
  • Diesel Engine

    Diesel Engine

    A single 10-foot iron cylinder with a flywheel at its base, ran on its own power for the first time, Made by Rudolf Diesel
  • The Fair Labor Standards Act

    The Fair Labor Standards Act

    Set national minimum wage and maximum hour standards for workers in interstate commerce, also placed limitations on child labor.
