Common features of all Nehalem based processors include an integrated DDR3 memory controller as well as QuickPath Interconnect or PCI Express and Direct Media Interface on the processor replacing the aging quad-pumped Front Side Bus used in all earlier Core processors. All these processors have 256 KB L2 cache per core, plus up to 12 MB shared L3 cache. Because of the new I/O interconnect, chipsets and mainboards from previous generations can no longer be used with Nehalem-based processors.
-
(3 M cache, 2.93 GHz, 1066 MHz FSB) on January 18, 2009.
-
(4 M cache, 2.67 GHz, 1333 MHz FSB) in April 2009.
-
(3 M cache, 3.06 GHz, 1066 MHz FSB) on May 31, 2009.
-
September 2009. It uses the Socket G1 socket type, runs at 1.6 GHZ, and features 6 MB L3 cache.
-
(8 M cache, 2.67 GHz, 1333 MHz FSB), on September 8, 2009.
-
January 2010
-
(12 M cache, 2.83 GHz, 1333 MHz FSB, 4 Cores, Socket 775) in January 2010.
-
-
-
January 7, 2010.
-
(3 M cache, 2.13 GHz, 1066 MHz FSB) and the i3-350M, on January 7, 2010.
-
July 2010. It runs at 3.2 GHz and features 12 MB L3 cache.
-
January 2011
-
This is the second generation of the Core processor microarchitecture. It kept all the existing brands from Nehalem, including Core i3/i5/i7, and introduced new model numbers. The initial set of Sandy Bridge processors includes dual- and quad-core variants, all of which use a single 32 nm die for both the CPU and integrated GPU cores, unlike the earlier microarchitectures.
-
The Core i3-2xxx line of desktop and mobile processors is a direct replacement of the 2010 "Clarkdale" Core i3-5xx and "Arrandale" Core i3-3xxM models, based on the new microarchitecture. While they require new sockets and chipsets, the user-visible features of the Core i3 are largely unchanged, including the lack of support for Turbo Boost and AES-NI. Unlike the Sandy Bridge-based Celeron and Pentium processors, the Core i3 line does support the new Advanced Vector Extensions.
-
The Core i5-2xxx line of desktop processors are mostly quad-core chips, with the exception of the dual-core Core i5-2390T, and include integrated graphics, combining the key features of the earlier Core i5-6xx and Core i5-7xx lines. The suffix after the four-digit model number designates unlocked multiplier (K), low-power (S) and ultra-low-power (T).
The i5-2xxxM processors are all dual-core and hyper-threaded chips like the previous Core i5-5xxM series, and share most of the features. -
Its Sandy Bridge models feature the largest amount of L3 cache and the highest clock frequency. Most of these models are very similar to their smaller Core i5 siblings. The quad-core mobile Core i7-2xxxQM/XM processors follow the previous "Clarksfield" Core i7-xxxQM/XM processors, but now also include integrated graphics.
-
The Ivy Bridge-based Core-i3-3xxx line is a minor upgrade to 22 nm process technology and better graphics.
-
-
Ivy Bridge is the codename for a "third generation" line of processors based on the 22 nm manufacturing process developed by Intel
-
They did two models, the A10 - 5700 and the A10 - 5800B with the following specs: 3.8GHz / 4MB L2 / 4 cores / Socket FM2
-
-
-
One of their fastest processors to date. It has 2 cores and runs at 3.6 GHz
-
It features an Iris Pro Graphics GPU 5200. Runs at 3.2 GHz and has a 6 MB L3 cache
-
The A6 Pro-7050B, A8 Pro-7150B and the A10 Pro-7350B . The y have one or two cores and run from 1.9 GHz to 2.2 GHz
-
Broadwell is the fifth generation Core processor microarchitecture, and was released by Intel on September 6, 2014, and began shipping in late 2014. It is the first to use a 14 nm chip. Additionally, mobile processors were launched in January 2015 and Desktop Core i5 and i7 processors were released in June 2015.
-
It is the first to use a 14 nm chip
-
Skylake is the sixth generation Core processor microarchitecture, and was launched in August 2015. Being the successor to the Broadwell line, it is a redesign using the same 14 nm manufacturing process technology; however the redesign has better CPU and GPU performance and reduced power consumption. Intel also disabled overclocking non -K processors.
-
Being the successor to the Broadwell line, it is a redesign using the same 14 nm manufacturing process technology; however the redesign has better CPU and GPU performance and reduced power consumption. Intel also disabled overclocking non -K processors.
-
The intel Core i7 - 6700 has 3.4 GHz, 8MB L3, 4 cores and an 1151 socket
-
Similar to Skylake, Kaby Lake processors are produced using a 14 nanometer manufacturing process technology.
-
the 1700, 1700X, and 1800X models (eight cores, run at 3.0 to 3.6 GHz) also they featured a 16Mb L3 Cache.
-
the i9-7900X uses the LGA 2066 socket, runs at 3.3 GHZ, has 10 cores, and features 13.75 MB L3 cache.
-
the Core i9-7980X, runs at 2.6 GHZ and features 24.75 MB L3 cache.
-
For the first time in the ten year history of Intel Core processors, the Coffee Lake generation features an increase in core counts across the desktop lineup of processors, a significant driver of improved performance versus previous generations despite similar per-clock performance.
-
the i9-8950HK, It uses the BGA 1440 socket, runs at 2.9 GHZ, has six cores, and features 12 MB L3 cache.
-
Cannon Lake (formerly Skymont) is Intel's codename for the 10-nanometer die shrink of the Kaby Lake microarchitecture.
-
Ice Lake is codename for Intel's 10th generation microarchitecture, representing an enhancement of the 'Architecture' of the preceding generation Kaby Lake/Cannon Lake processors (as specified in Intel's process–architecture–optimization execution plan). With Cannon Lake having successfully moved from a 14 nm to 10 nm manufacturing process, Ice Lake is also expected to feature an enhanced 10 nm process (10 nm+).
