history of welding

Timeline created by baileyanna345
  • Apr 3, 1000

    1000 B. C.

    1000 B. C.
    Welding can trace its historic development back to ancient times. The earliest examples come from the Bronze Age. Small gold circular boxes were made by pressure welding lap joints together. It is estimated that these boxes were made more than 2000 years ago. During the Iron Age the Egyptians and people in the eastern Mediterranean area learned to weld pieces of iron together. Many tools were found which were made approximately 1000 B.C.
  • Early 1800s

    Early 1800s
    Edmund Davy of England is credited with the discovery of acetylene in 1836. The production of an arc between two carbon electrodes using a battery is credited to Sir Humphry Davy in 1800. In the mid-nineteenth century, the electric generator was invented and arc lighting became popular. During the late 1800s, gas welding and cutting was developed. Arc welding with the carbon arc and metal arc was developed and resistance welding became a practical joining process.
  • Cabot labratory France

    Cabot labratory France
    Auguste De Meritens, working in the Cabot Laboratory in France, used the heat of an arc for joining lead plates for storage batteries in the year 1881. It was his pupil, a Russian, Nikolai N. Benardos, working in the French laboratory, who was granted a patent for welding. He, with a fellow Russian, Stanislaus Olszewski, secured a British patent in 1885 and an American patent in 1887. The patents show an early electrode holder. This was the beginning of carbon arc welding. Bernardos' efforts wer
  • introduction of the blowpipe torch

    Gas welding and cutting were perfected during this period as well. The production of oxygen and later the liquefying of air, along with the introduction of a blow pipe or torch in 1887, helped the development of both welding and cutting. Before 1900, hydrogen and coal gas were used with oxygen. However, in about 1900 a torch suitable for use with low-pressure acetylene was developed.
  • 1890 Detroit vs. Russia

    1890 Detroit vs. Russia
    In 1890, C.L. Coffin of Detroit was awarded the first U.S. patent for an arc welding process using a metal electrode. This was the first record of the metal melted from the electrode carried across the arc to deposit filler metal in the joint to make a weld. About the same time, N.G. Slavianoff, a Russian, presented the same idea of transferring metal across an arc, but to cast metal in a mold.
  • Coated metal electrode introduced in Great Britian

    Coated metal electrode introduced in Great Britian
    Approximately 1900, Strohmenger introduced a coated metal electrode in Great Britain. There was a thin coating of clay or lime, but it provided a more stable arc. Oscar Kjellberg of Sweden invented a covered or coated electrode during the period of 1907 to 1914. Stick electrodes were produced by dipping short lengths of bare iron wire in thick mixtures of carbonates and silicates, and allowing the coating to dry.
    Meanwhile, resistance welding processes were developed, including spot welding, se
  • World war I

    World War I brought a tremendous demand for armament production and welding was pressed into service. Many companies sprang up in America and in Europe to manufacture welding machines and electrodes to meet the requirements.
  • thermite welding

    In 1903, a German named Goldschmidt invented thermite welding that was first used to weld railroad rails.
  • American Welding Society founded

    American Welding Society founded
    Immediately after the war in 1919, twenty members of the Wartime Welding Committee of the Emergency Fleet Corporation under the leadership of Comfort Avery Adams, founded the American Welding Society as a nonprofit organization dedicated to the advancement of welding and allied processes.
  • Alternating Current invented

    Alternating current was invented in 1919 by C.J. Holslag; however it did not become popular until the 1930s when the heavy-coated electrode found widespread use.
  • Automatic welding introduced

    In 1920, automatic welding was introduced. It utilized bare electrode wire operated on direct current and utilized arc voltage as the basis of regulating the feed rate. Automatic welding was invented by P.O. Nobel of the General Electric Company. It was used to build up worn motor shafts and worn crane wheels. It was also used by the automobile industry to produce rear axle housings.
  • carbon and tungsten electrodes

    Research work was done utilizing gas shielding techniques. Alexander and Langmuir did work in chambers using hydrogen as a welding atmosphere. They utilized two electrodes starting with carbon electrodes but later changing to tungsten electrodes. The hydrogen was changed to atomic hydrogen in the arc. It was then blown out of the arc forming an intensely hot flame of atomic hydrogen during to the molecular form and liberating heat. This arc produced half again as much heat as an oxyacetylene fla
  • Gas Metal Arc Welding

    H.M. Hobart and P.K. Devers were doing similar work but using atmospheres of argon and helium. In their patents applied for in 1926, arc welding utilizing gas supplied around the arc was a forerunner of the gas tungsten arc welding process. They also showed welding with a concentric nozzle and with the electrode being fed as a wire through the nozzle. This was the forerunner of the gas metal arc welding process. These processes were developed much later.
  • Invention of various electrodes

    During the 1920s, various types of welding electrodes were developed. There was considerable controversy during the 1920s about the advantage of the heavy-coated rods versus light-coated rods. The heavy-coated electrodes, which were made by extruding, were developed by Langstroth and Wunder of the A.O. Smith Company and were used by that company in 1927. In 1929, Lincoln Electric Company produced extruded electrode rods that were sold to the public. By 1930, covered electrodes were widely used.
  • stud welding

    Stud welding was developed in 1930 at the New York Navy Yard, specifically for attaching wood decking over a metal surface. Stud welding became popular in the shipbuilding and construction industries.
  • submerged arc welding

    The automatic process that became popular was the submerged arc welding process. This "under powder" or smothered arc welding process was developed by the National Tube Company for a pipe mill at McKeesport, Pennsylvania. It was designed to make the longitudinal seams in the pipe. The process was patented by Robinoff in 1930 and was later sold to Linde Air Products Company, where it was renamed Unionmelt® welding. Submerged arc welding was used during the defense buildup in 1938 in shipyards and
  • GTAW

    Gas tungsten arc welding (GTAW) had its beginnings from an idea by C.L. Coffin to weld in a nonoxidizing gas atmosphere, which he patented in 1890. The concept was further refined in the late 1920s by H.M.Hobart, who used helium for shielding, and P.K. Devers, who used argon. This process was ideal for welding magnesium and also for welding stainless and aluminum. It was perfected in 1941, patented by Meredith, and named Heliarc® welding. It was later licensed to Linde Air Products, where the wa
  • Constant voltage poser force

    The gas shielded metal arc welding (GMAW) process was successfully developed at Battelle Memorial Institute in 1948 under the sponsorship of the Air Reduction Company. This development utilized the gas shielded arc similar to the gas tungsten arc, but replaced the tungsten electrode with a continuously fed electrode wire. One of the basic changes that made the process more usable was the small-diameter electrode wires and the constant-voltage poser source. This principle had been patented earlie
  • inert gas metal welding

    In 1953, Lyubavskii and Novoshilov announced the use of welding with consumable electrodes in an atmosphere of CO2 gas. The CO2 welding process immediately gained favor since it utilized equipment developed for inert gas metal arc welding, but could now be used for economically welding steels. The CO2 arc is a hot arc and the larger electrode wires required fairly high currents. The process became widely used with the introduction of smaller-diameter electrode wires and refined power supplies.
  • plasma arc welding

    Robert F. Gage invented plasma arc welding in 1957. This process uses a constricted arc or an arc through an orifice, which creates an arc plasma that has a higher temperature than the tungsten arc. It is also used for metal spraying and for cutting.
  • Electron beam welding

    The electron beam welding process, which uses a focused beam of electrons as a heat source in a vacuum chamber, was developed in France. J.A. Stohr of the French Atomic Energy Commission mad the first public disclosure of the process on November 23, 1957. In the United States, the automotive and aircraft engine industries are the major users of electron beam welding.
  • short circuit arc

    the short-circuit arc variation which was known as Micro-wire®, short-arc, and dip transfer welding, all of which appeared late in 1958 and early in 1959. This variation allowed all-position welding on thin materials and soon became the most popular of the gas metal arc welding process variations.
  • 1959

    In 1959, an inside-outside electrode was produced which did not require external gas shielding. The absence of shielding gas gave the process popularity for noncritical work. This process was named Innershield®.
  • electroslag

    The electroslag welding process was announced by the Soviets at the Brussels World Fair in Belgium in 1958. It had been used in the Soviet Union since 1951, but was based on work done in the United States by R.K. Hopkins, who was granted patents in 1940. The Hopkins process was never used to a very great degree for joining. The process was perfected and equipment was developed at the Paton Institute Laboratory in Kiev, Ukraine, and also at the Welding Research Laboratory in Bratislava, Czechoslo
  • pulsed current

    Another variation was the use of inert gas with small amounts of oxygen that provided the spray-type arc transfer. It became popular in the early 1960s. A recent variation is the use of pulsed current. The current is switched from a high to a low value at a rate of once or twice the line frequency.
  • 1961

    The Arcos Corporation introduced another vertical welding method, called Electrogas, in 1961. It utilized equipment developed for electroslag welding, but employed a flux-cored electrode wire and an externally supplied gas shield. It is an open arc process since a slag bath is not involved. A newer development uses self-shielding electrode wires and a variation uses solid wire but with gas shielding. These methods allow the welding of thinner materials than can be welded with the electroslag pro
  • friction welding and laser welding

    Friction welding, which uses rotational speed and upset pressure to provide friction heat, was developed in the Soviet Union. It is a specialized process and has applications only where a sufficient volume of similar parts is to be welded because of the initial expense for equipment and tooling. This process is called inertia welding. Laser welding is one of the newest processes. The laser was originally developed at the Bell Telephone Laboratories as a communications device. Because of the tr
