TRIANGULATED STRUCTURES

By cadss
  • 1000

    MATERIALS

    MATERIALS
    They are made up of bars, usually metal or wood. The triangulation makes the structure non-deformable
  • Jan 1, 1001

    THE BEGINNING

    THE BEGINNING
    the beginnings of triangulated structures began in prehistory, the first and best known to use them were the Egyptians in the 2nd millennium
  • 1002

    Tales de Mileto

    Tales de Mileto
    He was a Greek philosopher, mathematician, geometrist, physicist, and legislator. He lived and died in Miletus, a Greek polis on the Ionian coast. Aristotle considered him the initiator of the Miletus school, to which Anaximander and Anaximenes also belonged.
  • 1473

    PHOTO OF GEORG JOACHIM RHETICUS

    PHOTO OF GEORG JOACHIM RHETICUS
  • Period: 1514 to 1574

    Georg Joachim Rheticus

    He was an Austrian mathematician, astronomer, theologian, cartographer, musical instrument maker, and physician. He was a disciple of the Polish astronomer Nicolás Copernicus.
  • TRIANGULATED STRUCTURE AF A BRIDGE OF A RAILWAY

     TRIANGULATED STRUCTURE AF A BRIDGE OF A RAILWAY
    They are made up of bars, usually metal or wood. Triangulation makes the structure non-deformable, which is a good solution for bridge construction
  • TRIANGULATION OF STRUCTURES

     TRIANGULATION OF STRUCTURES
    There are many structures that are formed from triangles joined together, these structures that acquire great rigidity and have infinite applications.
  • Period: to

    WILLIAMSBURG BRIDGE

    Construction began in 1896, at a cost of $ 12,000,000.
    The bridge is an unconventional structure, unlike other suspension bridges, although the main span hangs from cables in the usual way, the main span of the bridge is 488 m long. The entire bridge is 2,227 m long, and the deck is 36 m wide. The height in the center of the bridge is 41 m and each tower is 102 m.
  • PHOTO OF WILLIAMSBURG BRIDGE

    PHOTO OF WILLIAMSBURG BRIDGE
  • VIADUCTO DE PINO

    VIADUCTO DE PINO
    a Spanish engineering work built to save the Duero River as it passes through the municipalities of Pino del Oro and Villadepera, in the province of Zamora, in the autonomous community of Castilla y León, Spain
  • ELECTRIC TOWER

    ELECTRIC TOWER
    It is a high-rise structure, normally built in steel latticework, whose main function is to support the electric power transmission lines.
  • GOLDEN GATE BRIDGE

    GOLDEN GATE BRIDGE
    it has so many wires forming its cables that it could flip the earth 3 times!
  • CRANE

    CRANE
    It is designed to lift and distribute all kinds of loads by means of a hook suspended from a cable; which in turn is moving by a car along a pen
  • LOUVRE TOWER

     LOUVRE TOWER
    The pyramid was designed by the Chinese-American architect Ieoh Ming Pei. The metal structure that supports the glass cladding is made of steel and aluminum and weighs 200 tons; It has a height of 21.64 meters on a square base of 35.42 meters on each side.
  • AKASHI KAIKYO

    AKASHI KAIKYO
    Akashi Strait Bridge is the suspension bridge that connects Honshū with Awaji Island, crossing one of the busiest straits in the world. It is 3,911 m long and its central span is 1991 m.
